HomeCLEO C10-1R
The compact design helps conserve counter space with its small footprint, and because peripherals are integrated into the all-in-one, it keeps workspaces uncluttered.
SHARE
OVERVIEW
Not Just a Pretty Face
Packed with power, the Cleo C10-1R POS delivers top performance in a compact, minimalistic design, elevating the checkout experience in retail and hospitality.
High-Speed Data Processing
Built on the latest technology that supports new, more demanding applications and databases. The Rockchip RK3568 processor, M.2 SSD memory ensure high-speed data processing and responsiveness in all situations.
Think Big, Act Small
The Cleo C10-1R is specially designed for counter-limited industries.
The compact design helps conserve counter space with its small footprint, and because peripherals are integrated into the all-in-one, it keeps workspaces uncluttered.
Key Features
- Embedded with 80/56mm thermal printer
- Available for Android
- High speed M.2 SSD
- Up to 16 GB DDR4 RAM
Optional Features
- MSR(Beep), IC Card Reader, Fingerprint, RFID
- 2D Barcode Scanner
- 5MP Camera
- CD-101C
Interested in Partner Tech Products?
| Item | C10-1R |
| Display | 10.1" |
| Aspect Ratio | 16:9 |
| Resolution | 800 x 1280 |
| Brightness (typical) | 250 nits |
| Touch | PCAP Touch |
| CPU | Rockchip RK3568 |
| Memory | DDR4 4GB |
| Storage | eMMc 64GB + 1x Micro SD Card Slot |
| External I/O Interface | 4 x USB 3.2 + 2 x USB 2.0 |
| 4 x Serial Ports, RS232 (RJ45), 0V/5V/12V Selection by UI (COM1, COM2, COM3, COM4) | |
| 1 x LAN (IEEE 802.3 10/ 100/ 1000 Mbps Ethernet, RJ45) | |
| 1 x RJ11 port supports 2 Cash drawers with 24V / 12V by jumper setting | |
| 1 x Audio (1 x Line-out) | |
| 1 x HDMI 2.1 | |
| 1 x DC + 24V input | |
| 1 x Micro SD card | |
| Speaker | 1 x Speaker 3W |
| Printer | 3" Thermal Printer |
| Optional Peripheral | MSR(Beep), IC Card Reader, Fingerprint, RFID |
| 2D Barcode Scanner | |
| 5MP Camera | |
| CD-101C | |
| WIFI/BT(option) | IEEE 802.11 a/b/g/n/ac/ax, BT 5.0 (on board) |
| Display Support | 2 Independent Displays (Main Display + CD-101C or HDMI) |
| Spill & Dust resistant | N/A |
| Operation System | Android 12 |
| TPM | N/A |
| Power Adaptor | AC-In 100~240V / DC-Out 24V, 72W |
| Reliability | System Operating Temperature:0~104°F/ 0~40°C |
| System Humidity: 15% ~ 80% | |
| Storage Temperature:-4~140°F/ -20~60°C | |
| Dimensions | 10.33 (W) x 11.49 (H) x 9.72 (D) in/ 262.26 (W) x 291.77 (H) x 247.13 (D) mm |
| Weight | 3.3 Kgs / 7.28 Ibs |
